300Mbps
REALTEK 8192FU chipset
5dBi directional antenna
Support IEEE 802.11b/g/n standard
USB 2.0 and 1.1 compliant
High Transmitter Power up to 2000mW max
| Software Specification | Hardware Specification | ||
| Chipset | RTL8192FU | Interface | USB2.0 Hi-Speed connector |
| Speed | 300Mbps | Operating Temperature | 0oC~40oC (32oF~104oF) |
| Standard | IEEE 802.11n,IEEE 802.11g, IEEE 802.11b | Storage Temperature | -40oC~70oC (-40oF~158oF) |
| Wireless Speed | 11n: Up to 300Mbps | Relative Humidity | 10% ~ 90%, non condensation |
| 11g: Up to 54Mbps | Storage Humidity | 5%~90% non-condensing | |
| 11b: Up to 11Mbps | |||
| Antenna | Double 5dBi RP-SMA dipole antenna | ||
| Frequency Range | 2.4-2.4835GHz | ||
| Wireless Transmit Power | 36dBm(MAX EIRP) | ||
| Modulation Type | OFDM/CCK/16-QAM/64-QAM | ||
| Receiver Sensitivity | 130M: -68dBm@10% PER | ||
| Work Mode | Ad-Hoc / Infrastructure | ||
| Wireless Security | 64/128 bits WEP | ||
| WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) | |||
| Support Operating System | Windows XP/Vista/Linux/ Win 7/Win8/Win10 | ||
