Product Code: 802.11n High Power Wireless USB Adapter

300Mbps
REALTEK 8192FU chipset
5dBi directional antenna
Support IEEE 802.11b/g/n standard
USB 2.0 and 1.1 compliant
High Transmitter Power up to 2000mW max
PARAMETERS
TECHNIC DATA
Software Specification Hardware Specification
Chipset                  RTL8192FU     Interface USB2.0 Hi-Speed connector
Speed 300Mbps Operating Temperature 0oC~40oC (32oF~104oF)
Standard IEEE 802.11n,IEEE 802.11g, IEEE 802.11b Storage Temperature -40oC~70oC (-40oF~158oF)
Wireless Speed 11n: Up to 300Mbps Relative Humidity 10% ~ 90%, non condensation
11g: Up to 54Mbps Storage Humidity 5%~90% non-condensing
11b: Up to 11Mbps
Antenna Double 5dBi RP-SMA dipole antenna
Frequency Range 2.4-2.4835GHz
Wireless Transmit Power 36dBm(MAX EIRP)
Modulation Type OFDM/CCK/16-QAM/64-QAM
Receiver Sensitivity 130M: -68dBm@10% PER
Work Mode Ad-Hoc / Infrastructure
Wireless Security 64/128 bits WEP
WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Support Operating System Windows XP/Vista/Linux/ Win 7/Win8/Win10
